Adjustable pedal circuit for Chevrolet Malibu VI (2003-2006)
Adjustable pedal circuit
ADJ PEDAL INHIBIT SW
ADJUSTABLE PEDALS ACTUATOR
ADJUSTABLE PEDALS MODULE
ADJUSTABLE PEDALS POSITION SENSOR (LEFT OF STEERING WHEEL)
ADJUSTABLE PEDALS POSITION SWITCH
BATTERY INHIBIT SIG SENS SIG GND LOW REF SENS SIG ENABLE SIG
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BODY CONTROL MODULE (BELOW RIGHT SIDE OF DASH, NEAR BLOWER MOTOR)
BRN/WHT WIRE
GRN WIRE
HOT AT ALL TIMES
LOGIC
LT BLU WIRE
LT GRN WIRE
PEDAL FUSE
PNK WIRE
PPL
PPL LT
RED WIRE
RED/WHT WIRE
RWD
WHT WIRE
YEL WIRE
