Automatic day/night mirror circuit for Chevrolet Malibu VI (2003-2006)
Automatic day/night mirror circuit
AMBIENT LIGHT SENSOR (WINDSHIELD SIDE)
BACKUP LP FUSE 17
BACKUP LP RELAY 33
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BELOW RIGHT SIDE OF DASH, NEAR BLOWER MOTOR)
BRN WIRE
DK BLU WIRE
GRN WIRE
GROUND
HEADLIGHT SENSOR (MIRROR SIDE)
HIGH SENSITIVITY SETTING
HOT AT ALL TIMES
HOT IN ACC AND RUN
IGN
INSIDE REARVIEW MIRROR
LOGIC BACKUP LAMP PWR
LOW SENSITIVITY SETTING
OFF MAX MIN
POWER TOPS SYSTEM
REAR FUSE BLOCK
RESETS TO DAYTIME HIGH REFLECTIVITY IN REVERSE
REV LMP RLY CTRL
ROOF/HEAT SEAT FUSE
WHT WIRE
YEL WIRE
