Electronic power steering circuit for Chevrolet Malibu VI (2003-2006)

Electronic power steering circuit

Get access

BLK WIRE BODY CONTROL MODULE (BELOW RIGHT SIDE OF DASH) COMPUTER DATA LINES SYSTEM EPS FUSE EPS FUSE 41 GROUND HIGH SPEED GMLAN SERIAL DATA (+) HOT AT ALL TIMES HOT IN RUN OR START IGN 1 VOLT LOGIC LT BLU WIRE PNK WIRE POSITION POWER STEERING CONTROL MODULE (LEFT OF STEERING COLUMN) POWER STEERING MOTOR PPL RED WIRE RED/BLK WIRE RT AST MTR CNTL LT AST MTR CNTL STEER SHAFT TORQUE SENS SIG 1 STEER WHEEL POSITION SEN LOW REF STEER WHEEL POSITION SEN SIGNAL 1 STEER WHEEL POSITION SEN SIGNAL 2 STEERING COLUMN ASSEMBLY TAN WIRE TAN/BLK WIRE TORQUE TORQUE/ POSITION SENSOR UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPART) WHT WIRE
