Chevrolet Malibu VI (2003-2006) w/ remote control outside heated mirrors Wiring diagram
This page shows the only wiring diagram for the component.w/ remote control outside heated mirrors, which is found in the car Chevrolet Malibu VI (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ remote control outside heated mirrors (1 of 1)
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BELOW RIGHT SIDE OF DASH, NEAR BLOWER MOTOR)
DEFOGGER SYSTEM
DOWN
DRIVER ELECTRIC OUTSIDE REARVIEW MIRROR
DRIVER PASSENGER
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT
LEFT RIGHT
NCA WIRE
ORG/ WIRE
OUTSIDE REARVIEW MIRROR SWITCH
PASSENGER
PASSENGER ELECTRIC OUTSIDE REARVIEW MIRROR
POWER MIRRORS FUSE
PPL
RED WIRE
RIGHT
UP DOWN
W/ REMOTE CONTROL OUTSIDE HEATED MIRRORS
WHT WIRE
Go to component -> Power mirrors circuit -> W/ REMOTE CONTROL OUTSIDE HEATED MIRRORS
