Chevrolet Malibu VI (2003-2006) resets to daytime high reflectivity in reverse Wiring diagram
This page shows the only wiring diagram for the component.resets to daytime high reflectivity in reverse, which is found in the car Chevrolet Malibu VI (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram resets to daytime high reflectivity in reverse (1 of 1)
AMBIENT LIGHT SENSOR (WINDSHIELD SIDE)
BACKUP LP FUSE 17
BACKUP LP RELAY 33
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BELOW RIGHT SIDE OF DASH, NEAR BLOWER MOTOR)
BRN WIRE
DK BLU WIRE
GRN WIRE
GROUND
HEADLIGHT SENSOR (MIRROR SIDE)
HIGH SENSITIVITY SETTING
HOT AT ALL TIMES
HOT IN ACC AND RUN
IGN
INSIDE REARVIEW MIRROR
LOGIC BACKUP LAMP PWR
LOW SENSITIVITY SETTING
OFF MAX MIN
POWER TOPS SYSTEM
REAR FUSE BLOCK
RESETS TO DAYTIME HIGH REFLECTIVITY IN REVERSE
REV LMP RLY CTRL
ROOF/HEAT SEAT FUSE
WHT WIRE
YEL WIRE
Go to component -> Automatic day/night mirror circuit -> RESETS TO DAYTIME HIGH REFLECTIVITY IN REVERSE
