Chevrolet Malibu VI (2003-2006) low ref clu rly ctrl high spd gm lan high spd gm lan Wiring diagram
This page shows the only wiring diagram for the component.low ref clu rly ctrl high spd gm lan high spd gm lan, which is found in the car Chevrolet Malibu VI (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram low ref clu rly ctrl high spd gm lan high spd gm lan (1 of 1)
2.2L, 3.5L
31 4 7 33 1 2 26 17 56 6 1 2 SENS SIG
A/C CLU FUSE 1
A/C CLUTCH RELAY 34
A/C COMPRESSOR CLUTCH
A/C REFRIGERANT PRESSURE SENSOR (RIGHT FRONT STRUT TOWER)
A/C REQ SIG
A/C REQ SIG LOW SPD GMLAN LOW SPD GMLAN
A/C REQUEST IND
A/C REQUEST SWITCH
AUTO A/C
BLK WIRE
BODY CONTROL MODULE (BCM) (BELOW RIGHT SIDE OF DASH, NEAR BLOWER MOTOR)
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
DK GRN/WHT WIRE
GRY WIRE
HIGH SPEED GM LAN SERIAL DATA
HOT AT ALL TIMES
HOT IN RUN OR START
HVAC CONTROL MODULE (CENTER OF DASH) LOGIC
LOGIC
LOW REF CLU RLY CTRL HIGH SPD GM LAN HIGH SPD GM LAN
LOW SPEED GM LAN SERIAL DATA
MAN A/C
MODE SWITCH
ORG/BLK WIRE
POWERTRAIN CONTROL MODULE (PCM) (FRONT OF BATTERY)
TAN WIRE
TAN/BLK WIRE
TEMPERATURE CONTROL
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
Go to component -> Compressor circuit -> LOW REF CLU RLY CTRL HIGH SPD GM LAN HIGH SPD GM LAN
