Chevrolet Malibu VI (2003-2006) blr mtr spd ctrl Wiring diagram
This page shows the only wiring diagram for the component.blr mtr spd ctrl, which is found in the car Chevrolet Malibu VI (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram blr mtr spd ctrl (1 of 1)
A/C CLU FUSE 1
A/C CLUTCH RELAY 34
A/C COMPRESSOR CLUTCH
A/C REQUEST IND
A/C REQUEST SWITCH
BLK WIRE
BLK/WHT WIRE
BLOWER MOTOR (BELOW RIGHT SIDE OF DASH)
BLOWER MOTOR CONTROL MODULE (RIGHT SIDE OF DASH, REAR OF HVAC CASE)
BLOWER MOTOR SWITCH
BLR MTR SPD CTRL
BLR SPD REQ SIG
BRN WIRE
C/FAN 1 FUSE 17
C/FAN 2 FUSE 18
COMPUTER DATA LINES SYSTEM
COOL SER/PAR RELAY 29
COOL/ FAN 1 RELAY 28
COOL/ FAN 2 RELAY 30
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
FRESH AIR IND
GRD
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
HVAC CONTROL MODULE (CENTER OF DASH)
IGN 3
INSIDE AIR TEMPERATURE SENSOR
LEFT COOLING FAN
LMP SPLY VOLTAGE
LOGIC
LOW REF LOW REF DR CTRL B DR CTRL B DR CTRL B
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
MODE SWITCH TEMPERATURE CONTROL
PNK/WHT WIRE
PPL
RECIRCULATION ACTUATOR
RECIRCULATION IND
RED/BLK WIRE
RED/WHT WIRE
RIGHT COOLING FAN
SPLY VOLTAGE
TAN WIRE
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component -> Automatic a/c circuit (1 of 2) -> BLR MTR SPD CTRL
