Chevrolet Malibu VI (2003-2006) 5 volt reference low reference Wiring diagram
This page shows the only wiring diagram for the component.5 volt reference low reference, which is found in the car Chevrolet Malibu VI (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 5 volt reference low reference (1 of 1)
5 VOLT REFERENCE LOW REFERENCE
A/T SHIFT LOCK CONTROL ASSEMBLY
A/T SHIFT LOCK CONTROL SOLENOID
A/T SHIFT LOCK CTRL SOLENOID SUPPLY VOLTAGE
BATTERY
BLK WIRE
BODY CONTROL MODULE (BCM) (BELOW RIGHT SIDE OF DASH, NEAR BLOWER MOTOR)
BRAKE PEDAL POSITION SENSOR (ON BRAKE PEDAL SUPPORT)
BRAKE PEDAL POSITION SENSOR SIGNAL
BRN WIRE
DK GRN WIRE
DOOR LOCKS FUSE
GROUND
HOT AT ALL TIMES
INTERIOR LIGHTS FUSE
LOGIC
WHT WIRE
YEL WIRE
Go to component -> Shift interlock circuit -> 5 VOLT REFERENCE LOW REFERENCE
