Wiper/washer circuit for Chevrolet Malibu V facelift (2000-2003)
Wiper/washer circuit
24,000 OHMS
BLK WIRE
BODY COMPUTER MODULE (BELOW RIGHT SIDE OF DASH) LOW WASHER FLUID INPUT
DK GRN WIRE
GRY WIRE
HIGH LOW
HIGH OFF LOW
HOT IN ACCY, RUN
LEFT I/P JUNCTION BLOCK (ON LEFT END OF DASH)
MIST
MIST OFF
MUX 2 HIGH B+ MUX 1
PPL
RED WIRE
WASHER FLUID LEVEL SENSOR (INSIDE LEFT FRONT FENDER)
WASHER SWITCH
WHT WIRE
WINDSHIELD WASHER FLUID PUMP (BETWEEN WASHER FLUID RESERVOIR, FRAME RAIL)
WIPER FUSE
WIPER MOTOR ASSEMBLY (ON LEFT REAR OF ENGINE COMPARTMENT)
WIPER MOTOR CONTROL
WIPER SWITCH
YEL WIRE
