Shift interlock circuit for Chevrolet Malibu V facelift (2000-2003)
Shift interlock circuit
AUTOMATIC TRANSMISSION SHIFT LOCK CONTROL ACTUATOR (UNDER CENTER CONSOLE)
B-U LMP/BTSI FUSE
BLK WIRE
BRAKE SWITCH (OPEN WITH BRAKE PEDAL DEPRESSED) (ON BRAKE PEDAL SUPPORT)
DK GRN/WHT WIRE
GROUND SPLICE PACK (RIGHT SIDE OF DASH)
HOT IN RUN OR START
LEFT I/P JUNCTION BLOCK (LEFT SIDE OF DASH,
LT GRN WIRE
PARK/ NEUTRAL POSITION SWITCH (ON SIDE OF
PNK WIRE
TRANSAXLE
UNDERHOOD JUNCTION BLOCK
