Radio circuits for Chevrolet Malibu V facelift (2000-2003)
Radio circuits
ANTENNA
BATTERY VOLTAGE
BLK WIRE
BLK/WHT WIRE
BRN WIRE
CLASS 2 DATA
COMPUTER DATA LINES SYSTEM
DIM DISPLAY IN
DK BLU WIRE
DK GRN WIRE
GRD
GROUND
GROUND SPLICE PACK
GRY WIRE
HOT AT ALL TIMES
LEFT FRONT SPEAKER
LEFT I/P JUNCTION BLOCK (ON LEFT END OF DASH)
LEFT REAR SPEAKER
LF SPEAKER (+)
LR SPEAKER (+)
LT BLU WIRE
LT GRN WIRE
NCA WIRE
ORG/ WIRE
PARK LAMP IN
PPL
RADIO
RADIO BATTERY FUSE
RF SPEAKER (+)
RIGHT FRONT SPEAKER
RIGHT I/P JUNCTION BLOCK (ON RIGHT END OF DASH)
RIGHT REAR SPEAKER
RR SPEAKER (+)
TAN WIRE
WHT WIRE
YEL WIRE
