Power mirror circuit for Chevrolet Malibu V facelift (2000-2003)
Power mirror circuit
+DOWN VERT +UP
+RIGHT HORZ +LEFT
BLK WIRE
BRN/BLU WIRE
DK BLU WIRE
DRIVER OUTSIDE REARVIEW MIRROR
GROUND SPLICE PACK (BELOW LEFT SIDE OF DRIVER'S SEAT)
GRY (OR WIRE
GRY WIRE
HOT AT ALL TIMES POWER MIRROR FUSE
LEFT
LEFT I/P JUNCTION BLOCK (UNDER LEFT END OF DASH)
LT BLU (OR WIRE
LT BLU WIRE
LT GRN WIRE
OFF
ORG/ WIRE
OUTSIDE REARVIEW MIRROR SWITCH
PASSENGER OUTSIDE REARVIEW MIRROR
PPL/ WHT WIRE
PPL/WHT WIRE
RED/ WHT WIRE
RED/WHT WIRE
RIGHT
RIGHT/ LEFT SELECT SWITCH LEFT
WHT WIRE
