Courtesy lamps circuit for Chevrolet Malibu V facelift (2000-2003)
Courtesy lamps circuit
BLK WIRE
BODY CONTROL MODULE (BELOW RIGHT SIDE OF DASH, NEAR BLOWER MOTOR)
DOME LAMP
DOOR
GLOVE BOX LAMP/ SWITCH
GRN WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER
INT LPS FUSE
LEFT COURTESY LAMP
LEFT FRONT DOOR AJAR INPUT
LEFT FRONT DOOR LOCK ASSEMBLY
LEFT I/P JUNCTION BLOCK (ON LEFT END OF DASH)
LEFT REAR DOOR LOCK ASSEMBLY
LT BLU WIRE
LT BLU/BLK WIRE
LT GRN/BLK WIRE
OFF
ORG/ WIRE
ORG/BLK WIRE
PNK/BLK WIRE
REAR COMPARTMENT COURTESY LAMP
REAR COMPARTMENT LID RELEASE MOTOR (IN REAR COMPARTMENT LID)
REAR VIEW MIRROR READING LAMPS
RIGHT COURTESY LAMP
RIGHT FRONT DOOR LOCK ASSEMBLY
RIGHT I/P JUNCTION BLOCK (ON RIGHT END OF DASH)
RIGHT REAR DOOR LOCK ASSEMBLY
RIGHT VANITY MIRROR LAMPS
SPI CLOCK
SPI DATA RECIEVE
SPI DATA TRANSMIT
WHT WIRE
YEL WIRE
