Cruise control circuit for Chevrolet Malibu V facelift (2000-2003)
Cruise control circuit
BLK WIRE
BRAKE SWITCH (ON BRAKE PEDAL SUPPORT)
BRN WIRE
CRUISE CONTROL MODULE (RIGHT SIDE OF ENGINE COMPT)
CRUISE CONTROL ON/OFF SWITCH
CRUISE DISABLE OUTPUT
CRUISE ENGAGED INPUT
CRUISE FUSE
CRUISE SW FUSE
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
GRY WIRE
GRY/BLK WIRE
HOT IN RUN
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL
LEFT I/P JUNCTION BLOCK (LEFT END OF DASH)
LT BLU WIRE
LT BLU/BLK WIRE
NCA WIRE
OFF
OFF ON
PNK WIRE
POWERTRAIN CONTROL MODULE (PCM) (BELOW LEFT SIDE OF DASH)
PPL
PPL VSS LOW
R/A
RIGHT I/P JUNCTION BLOCK (RIGHT END OF DASH)
S/C
UNDERHOOD JUNCTION BLOCK (LEFT SIDE OF ENGINE COMPARTMENT)
VEHICLE SPEED SENSOR (VSS) (ON REAR OF ENGINE/TRANSAXLE)
VSS HIGH
VSS OUTPUT
YEL WIRE
