Chevrolet Malibu V facelift (2000-2003) front passenger lock actuator Wiring diagram
This page shows the only wiring diagram for the component.front passenger lock actuator, which is found in the car Chevrolet Malibu V facelift (2000-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger lock actuator (1 of 1)
1 2 3 4 B+ SERIAL DATA SIG PPL
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (RIGHT SIDE OF DASH, NEAR BLOWER MOTOR)
DOOR LOCK FUSE
DOOR LOCK RELAY
DOOR SIGNAL LOCK/UNLOCK
DOOR UNLOCK RELAY
DRIV DR UNLOCK CTRL DOOR LOCK CTRL SERIAL DATA SIG DOOR UNLOCK CTRL
DRIVER DOOR LOCK ACTUATOR
DRIVER DOOR LOCK SWITCH
DRIVER DOOR UNLOCK RELAY
FRONT PASSENGER LOCK ACTUATOR
FRONT PASSENGER LOCK SWITCH
GROUND
GROUND SPLICE PACK (LEFT END OF DASH)
GRY WIRE
HOT AT ALL TIMES
LEFT I/P JUNCTION BLOCK
LEFT REAR DOOR LOCK ACTUATOR
LOCK
LT BLU WIRE
ORG/ WIRE
PPL
REMOTE CONTROL DOOR LOCK RECEIVER (RFA) (ON REAR PACKAGE SHELF)
RIGHT I/P FUSE BLOCK
RIGHT REAR DOOR LOCK ACTUATOR
TAN WIRE
TRUNK REL CTRL
TRUNK REL/RFA FUSE
TRUNK RELEASE
UNLOCK
WHT WIRE
WITH RFA
YEL WIRE
Go to component -> Power door lock circuit -> FRONT PASSENGER LOCK ACTUATOR
