Chevrolet Malibu V facelift (2000-2003) driv dr unlock ctrl door lock ctrl serial data sig door unlock ctrl Wiring diagram

1 2 3 4 B+ SERIAL DATA SIG PPL BLK WIRE BLU WIRE BODY CONTROL MODULE (RIGHT SIDE OF DASH, NEAR BLOWER MOTOR) DOOR LOCK FUSE DOOR LOCK RELAY DOOR SIGNAL LOCK/UNLOCK DOOR UNLOCK RELAY DRIV DR UNLOCK CTRL DOOR LOCK CTRL SERIAL DATA SIG DOOR UNLOCK CTRL DRIVER DOOR LOCK ACTUATOR DRIVER DOOR LOCK SWITCH DRIVER DOOR UNLOCK RELAY FRONT PASSENGER LOCK ACTUATOR FRONT PASSENGER LOCK SWITCH GROUND GROUND SPLICE PACK (LEFT END OF DASH) GRY WIRE HOT AT ALL TIMES LEFT I/P JUNCTION BLOCK LEFT REAR DOOR LOCK ACTUATOR LOCK LT BLU WIRE ORG/ WIRE PPL REMOTE CONTROL DOOR LOCK RECEIVER (RFA) (ON REAR PACKAGE SHELF) RIGHT I/P FUSE BLOCK RIGHT REAR DOOR LOCK ACTUATOR TAN WIRE TRUNK REL CTRL TRUNK REL/RFA FUSE TRUNK RELEASE UNLOCK WHT WIRE WITH RFA YEL WIRE
