Chevrolet Malibu V facelift (2000-2003) defog request dim input Wiring diagram
This page shows the only wiring diagram for the component.defog request dim input, which is found in the car Chevrolet Malibu V facelift (2000-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram defog request dim input (1 of 1)
AIR CONDITIONING SYSTEM
BLK WIRE
BLK/WHT WIRE
BRN WIRE
DEFOG REQUEST DIM INPUT
DEFOGGER SWITCH
EXTERIOR LIGHTS
GROUND SPLICE PACK (LEFT SIDE OF DASH)
GROUND SPLICE PACK (RIGHT SIDE OF REAR PACKAGE SHELF)
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN
HTR A/C IGN FUSE
HVAC CONTROL ASSEMBLY
IGN DEFOG INDICATOR TIMER
INTERIOR LIGHTS
LEFT I/P JUNCTION BLOCK
ON INDICATOR GROUND
PANEL LAMP
PPL
REAR DEFOGGER RELAY
REAR WINDOW DEFOGGER GRID
RELAY CTRL
RR DEFOG FUSE
UNDERHOOD JUNCTION BLOCK
WHT WIRE
Go to component -> Defogger circuit -> DEFOG REQUEST DIM INPUT
