Chevrolet Malibu V facelift (2000-2003) cruise disable output Wiring diagram
This page shows the only wiring diagram for the component.cruise disable output, which is found in the car Chevrolet Malibu V facelift (2000-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cruise disable output (1 of 1)
BLK WIRE
BRAKE SWITCH (ON BRAKE PEDAL SUPPORT)
BRN WIRE
CRUISE CONTROL MODULE (RIGHT SIDE OF ENGINE COMPT)
CRUISE CONTROL ON/OFF SWITCH
CRUISE DISABLE OUTPUT
CRUISE ENGAGED INPUT
CRUISE FUSE
CRUISE SW FUSE
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
GRY WIRE
GRY/BLK WIRE
HOT IN RUN
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL
LEFT I/P JUNCTION BLOCK (LEFT END OF DASH)
LT BLU WIRE
LT BLU/BLK WIRE
NCA WIRE
OFF
OFF ON
PNK WIRE
POWERTRAIN CONTROL MODULE (PCM) (BELOW LEFT SIDE OF DASH)
PPL
PPL VSS LOW
R/A
RIGHT I/P JUNCTION BLOCK (RIGHT END OF DASH)
S/C
UNDERHOOD JUNCTION BLOCK (LEFT SIDE OF ENGINE COMPARTMENT)
VEHICLE SPEED SENSOR (VSS) (ON REAR OF ENGINE/TRANSAXLE)
VSS HIGH
VSS OUTPUT
YEL WIRE
Go to component -> Cruise control circuit -> CRUISE DISABLE OUTPUT
