Chevrolet Malibu V facelift (2000-2003) alc relay control fog light relay control park lamp sw sig on horn rly ctrl wiring diagram

A/C BFC FUSE AIR CONDITIONING SYSTEM ALC RELAY CONTROL FOG LIGHT RELAY CONTROL PARK LAMP SW SIG ON HORN RLY CTRL AMBIENT LIGHT SENSOR (ON TOP OF DASH TRIM PAD) ANTI-THEFT SYSTEM INSTRUMENT CLUSTER SYSTEM EXTERIOR LIGHTS SYSTEM BFC BATT FUSE BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BELOW RIGHT SIDE OF DASH, NEAR BLOWER MOTOR) BRAKE FLUID LEVEL SWITCH (ON BRAKE MASTER CYLINDER RESERVOIR) BRN WIRE COMPUTER DATA LINES SYSTEM DOOR LOCKS SYSTEM ANTI-THEFT SYSTEM CRUISE FUSE DK BLU WIRE DK GRN/WHT WIRE DOOR LOCK UNLOCK AMBIENT LIGHT SENSOR SIGNAL DOOR LOCKS SYSTEM INSTRUMENT CLUSTER SYSTEM HEADLIGHTS SYSTEM DRIVER DR UNLOCK CTRL SERIAL DATA SPI DATA TRANSMIT FOG LIGHT SWITCH INPUT DRL RELAY CONTROL ENGINE COOLANT LEVEL SWITCH (ON ENGINE COOLANT SURGE TANK) FUSE GROUND SPLICE PACK GRY/BLK WIRE HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM HORNS SYSTEM HORNS SYSTEM HOT AT ALL TIMES HOT IN ACCY, RUN, OR START HOT IN RUN HOT IN RUN OR START IGNITION SWITCH INSTRUMENT CLUSTER SYSTEM DOOR LOCKS SYSTEM INT LPS FUSE IPC/BFC KEY WARNING SWITCH LEFT FRONT DOOR AJAR INPUT IGNITION 3 POSITIVE VOLTAGE LEFT I/P JUNCTION BLOCK LOW BEAM HEADLIGHT INPUT LOW ENGINE COOLANT INPUT A/C SWITCH REQUEST INPUT LOW WASHER SOLVENT INPUT SERIAL DATA SPI CLOCK ALL DR LOCK CTRL LT BLU WIRE LT BLU/BLK WIRE LT GRN WIRE LT GRN/BLK WIRE ORG/ WIRE PNK BRAKE FLUID SW IN INADVERTENT POWER INPUT WIRE PNK WIRE PNK/BLK WIRE PNK/WHT WIRE PPL PPL IGNITION 0 POSITIVE VOLTAGE PARK LIGHT RELAY CTRL REAR COMPT RELEASE CTRL RIGHT I/P JUNCTION BLOCK TRUNK RELEASE CIRCUIT UNDERHOOD JUNCTION BLOCK WARNING SYSTEMS SYSTEM WARNING SYSTEMS SYSTEM SUPPLEMENTAL RESTRAINTS SYSTEM WASHER FLUID LEVEL SENSOR (INSIDE LEFT FRONT FENDER) WHT WIRE YEL WIRE YEL/BLK WIRE
