Trunk release circuit for Chevrolet Malibu IX facelift (2018-2024)
Trunk release circuit
BLK WIRE
BLU WIRE
BLU/YEL WIRE
BODY CONTROL MODULE (CENTER OF DASH)
COMPUTER DATA LINES SYSTEM
DRIVER INFORMATION CENTER DISPLAY
EXTERIOR REAR COMPARTMENT LID UNLATCH SWITCH
GRN WIRE
GROUND
GRY WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL FUSE BLOCK
LIFTGATE AJAR SW SIG 1
LIFTGLASS/REAR COMP LID MTR RELEASE CTRL
LO SPD GMLAN SERIAL DATA
LOGIC INSTRUMENT CLUSTER
POWER SUPPLY TRANSFORMER
REAR CLOSURE HNDL SW OPEN SIG
REAR COMPARTMENT LID LATCH
REAR COMPARTMENT LID UNLATCH RELAY
RED WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/YEL WIRE
SUPPLY
UNDERHOOD FUSE BLOCK
VIO/GRY WIRE
W/ STOP/ START
W/O STOP/ START
YEL/BLU WIRE
