Ground distribution circuit for Chevrolet Malibu IX facelift (2018-2024)
Ground distribution circuit (1 of 6)
ACTIVE GRILLE AIR SHUTTER 1 ACTUATOR
BLK WIRE
BRAKE FLUID LEVEL SWITCH
ENGINE HOOD SWITCH
IGNITION MAIN RELAY
LEFT DAYTIME RUNNING LAMP,
LEFT FRONT SIDE MARKER LAMP
LEFT HEADLAMP ASSEMBLY
LEFT HIGH BEAM HEADLAMP
LEFT HIGH BEAM SOLENOID ACTUATOR
LEFT HORN
LEFT LOW BEAM HEADLAMP
LEFT LOWER PARK/DAYTIME RUNNING LAMP
LEFT PARK/DAYTIME RUNNING LAMP
REAR COMPARTMENT LID UNLATCH RELAY
REAR DEFOGGER RELAY
RIGHT DAYTIME RUNNING LAMP
RIGHT FRONT SIDE MARKER LAMP
RIGHT FRONT TURN SIGNAL LAMP
RIGHT HEADLAMP ASSEMBLY
RIGHT HIGH BEAM HEADLAMP
RIGHT HIGH BEAM SOLENOID ACTUATOR
RIGHT HORN
RIGHT LOW BEAM HEADLAMP
RIGHT LOWER PARK/DAYTIME RUNNING LAMP
RIGHT PARK/DAYTIME RUNNING LAMP
W/ LED
W/ PARK ASSIST
W/O LED
WINDSHIELD WASHER FLUID LEVEL SENSOR
WINDSHIELD WASHER PUMP
WINDSHIELD WASHER PUMP RELAY
WINDSHIELD WIPER RELAY
WINDSHIELD WIPER SPEED CONTROL RELAY
Ground distribution circuit (2 of 6)
BLK WIRE
BLK/WHT WIRE
CENTER CONSOLE FLOOD LAMP
COOLING FAN MOTOR
DATA LINK CONNECTOR
HAZARD WARNING SWITCH
HORN SWITCH
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE
INSTRUMENT PANEL ACCENT LAMP
INSTRUMENT PANEL FUSE BLOCK
INSTRUMENT PANEL MULTI- FUNCTION SWITCH
LEFT STEERING WHEEL CONTROLS SWITCH
LONG RANGE RADAR SENSOR MODULE
NCA WIRE
PARK BRAKE CONTROL SWITCH
PARK POSITION SWITCH
PASSENGER PRESENCE MODULE
POWER STEERING CONTROL MODULE
RADIO PRESETS STEERING WHEEL CONTROLS SWITCH
RADIO VOLUME STEERING WHEEL CONTROLS SWITCH
RETAINED ACCESSORY POWER RELAY
RIGHT REAR WINDOW DEFOGGER NOISE FILTER
RIGHT STEERING WHEEL CONTROLS SWITCH
STEERING WHEEL AIR BAG COIL
STEERING WHEEL HEATER
STEERING WHEEL HEATING CONTROL MODULE
TRANSMISSION MANUAL SHIFT SWITCH
TRANSMISSION SHIFT LEVER
TRANSMISSION SHIFT LOCK CONTROL SOLENOID ACTUATOR
W/ INTEGRATED BRAKE ASSIST
Ground distribution circuit (3 of 6)
2.0L
A/C COMPRESSOR
A/C COMPRESSOR CLUTCH
ACCESSORY DC/ AC POWER INVERTER MODULE
AUTOMATIC TRANSMISSION ASSEMBLY
AUXILIARY AUDIO INPUT
AUXILIARY HEATER COOLANT PUMP
BATTERY
BATTERY CURRENT SENSOR
BATTERY SENSOR MODULE
BLK WIRE
BLK/WHT WIRE
BLOWER MOTOR
BODY CONTROL MODULE
CENTER CONSOLE ACCESSORY POWER RECEPTACLE
ELECTRIC/ AUXILIARY TRANSMISSION FLUID PUMP
ENGINE CONTROL MODULE
ENGINE OIL LEVEL SWITCH
INSTRUMENT PANEL ACCESSORY POWER RECEPTACLE
LOGIC
MOBILE DEVICE WIRELESS CHARGER MODULE
MULTI-FUNCTION INTAKE AIR SENSOR
RADIO
STARTER RELAY
TELEMATICS COMMUNICATION INTERFACE CONTROL MODULE
TRANSMISSION CONTROL MODULE
USB RECEPTACLE
W/ ONSTAR
W/ START/ STOP SYSTEM
W/ START/STOP SYSTEM
W/O START STOP SYSTEM
Ground distribution circuit (4 of 6)
AMBIENT LIGHT/ SUNLOAD SENSOR LOGIC
AUDIO AMPLIFIER
BLK WIRE
BODY CONTROL MODULE
BRN WIRE
COLLISION ALERT INDICATORS
DATA LINK CONNECTOR
ELECTRONIC BRAKE CONTROL MODULE
FRONT SEAT HEATING CONTROL MODULE
HEADLAMP SWITCH
HVAC CONTROL MODULE
IGNITION MODE SWITCH
INSTRUMENT CLUSTER LOGIC
KEYLESS ENTRY CONTROL MODULE
PASSENGER BACK SEAT BLOWER MOTOR
PASSENGER CUSHION SEAT BLOWER MOTOR
PASSENGER SEAT ADJUSTER SWITCH
PASSENGER SEAT LUMBAR SUPPORT SWITCH
PASSENGER WINDOW SWITCH LOGIC
POWER SUPPLY TRANSFORMER
REAR SEAT HEATING CONTROL MODULE
RIGHT REAR WINDOW SWITCH LOGIC
SERIAL DATA GATEWAY MODULE
TRANSMISSION SHIFT LEVER POSITION INDICATOR LOGIC
TURN SIGNAL/ MULTI-FUNCTION SWITCH
UNDERHOOD FUSE BLOCK
W/ 4 WAY SEAT ADJUSTER
W/ MEMORY
W/ POWER OPERATED PARKING BRAKE
W/ START/ STOP SYSTEM
W/O 4 WAY SEAT ADJUSTER
W/O MEMORY
W/O ONSTAR
WINDSHIELD WIPER MOTOR
WINDSHIELD WIPER RELAY
WINDSHIELD WIPER SPEED CONTROL RELAY
YEL WIRE
YEL/BRN WIRE
Ground distribution circuit (5 of 6)
BLK WIRE
DRIVER BACK SEAT BLOWER MOTOR
DRIVER CUSHION SEAT BLOWER MOTOR
DRIVER DOOR HANDLE FLOOD LAMP
DRIVER DOOR LATCH ASSEMBLY
DRIVER DOOR POCKET FLOOD LAMP
DRIVER EXTERIOR DOOR HANDLE ASSEMBLY
DRIVER EXTERIOR DOOR HANDLE SWITCH
DRIVER OUTSIDE REAR VIEW MIRROR GLASS
DRIVER OUTSIDE REAR- VIEW MIRROR
DRIVER SEAT ADJUSTER SWITCH
DRIVER SEAT LUMBAR SUPPORT SWITCH
DRIVER WINDOW MOTOR
DRIVER WINDOW/ OUTSIDE REAR VIEW MIRROR SWITCH
INSIDE REAR VIEW MIRROR
LEFT REAR DOOR LATCH ASSEMBLY
LEFT REAR SEAT HEATING SWITCH
LEFT REAR WINDOW SWITCH
LOGIC
PASSENGER DOOR HANDLE FLOOD LAMP
PASSENGER DOOR LATCH ASSEMBLY
PASSENGER DOOR LOCK SWITCH
PASSENGER EXTERIOR DOOR HANDLE ASSEMBLY
PASSENGER EXTERIOR DOOR HANDLE SWITCH
PASSENGER OUTSIDE REAR VIEW MIRROR
PASSENGER OUTSIDE REAR VIEW MIRROR GLASS
RIGHT REAR DOOR LATCH ASSEMBLY
RIGHT REAR SEAT HEATING SWITCH
RIGHT TURN SIGNAL REPEATER LAMP
SEAT MEMORY CONTROL MODULE
W/ 2 WAY LUMBAR
W/ EXPRESS UP/DOWN
W/ MEMORY
W/O 2 WAY LUMBAR
W/O EXPRESS UP/DOWN
WHT/BLK WIRE
WINDSHIELD FRONT VIEW CAMERA
Ground distribution circuit (6 of 6)
ACTIVE SAFETY CONTROL MODULE
BLK WIRE
BRN WIRE
CENTER HIGH MOUNTED STOP LAMP
EXTERIOR REAR COMPARTMENT LID UNLATCH SWITCH
FRONT OVERHEAD CONSOLE ASSEMBLY
FUEL PUMP DRIVER CONTROL MODULE
LEFT BACKUP LAMP
LEFT LICENSE PLATE LAMP
LEFT REAR COMPARTMENT LID TAIL LAMP ASSEMBLY
LEFT REAR SEAT SIDE AIR BAG
LEFT REAR SIDE MARKER LAMP
LEFT SIDE OBJECT SENSOR MODULE
LEFT SUNSHADE
LEFT TAIL LAMP
LEFT TAIL LAMP ASSEMBLY
LEFT TAIL/STOP LAMP
NCA WIRE
PARKING ASSIST CONTROL MODULE
REAR COMPARTMENT COURTESY LAMP
REAR COMPARTMENT LID LATCH
REAR VIEW CAMERA
RIGHT BACKUP LAMP
RIGHT LICENSE PLATE LAMP
RIGHT REAR COMPARTMENT LID TAIL LAMP ASSEMBLY
RIGHT REAR SEAT SIDE AIR BAG
RIGHT REAR SIDE MARKER LAMP
RIGHT SIDE OBJECT SENSOR MODULE
RIGHT SUNSHADE
RIGHT TAIL LAMP
RIGHT TAIL LAMP ASSEMBLY
RIGHT TAIL/STOP LAMP
SUNROOF MOTOR
W/ INTEGRATED BRAKE ASSIST
