Chevrolet Malibu IX facelift (2018-2024) transmission control solenoid valve 10 Wiring diagram
This page shows the only wiring diagram for the component.transmission control solenoid valve 10, which is found in the car Chevrolet Malibu IX facelift (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram transmission control solenoid valve 10 (1 of 1)
AUTOMATIC TRANSMISSION ASSEMBLY
BLK/BRN WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
ENGINE CONTROL MODULE (LEFT FRONT OF ENGINE COMPT)
GRN/BRN WIRE
GRN/GRY WIRE
GRN/YEL WIRE
GRY WIRE
GRY/BLK WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/GRN WIRE
HI SPD GMLAN SERIAL DATA (+) (3)
IGN MODE SW MODE CTRL BACKUP
IMS MODE SW LO REF
NCA WIRE
TRANSMISSION CONTROL SOLENOID VALVE 1
TRANSMISSION CONTROL SOLENOID VALVE 10
TRANSMISSION CONTROL SOLENOID VALVE 2
TRANSMISSION CONTROL SOLENOID VALVE 3
TRANSMISSION CONTROL SOLENOID VALVE 4
TRANSMISSION CONTROL SOLENOID VALVE 5
TRANSMISSION CONTROL SOLENOID VALVE 6
TRANSMISSION CONTROL SOLENOID VALVE 7
TRANSMISSION CONTROL SOLENOID VALVE 8
TRANSMISSION CONTROL SOLENOID VALVE 9
TRANSMISSION FLUID TEMPERATURE SENSOR
TRANSMISSION INTERNAL MODE SWITCH
TRANSMISSION OUTPUT SHAFT SPEED SENSOR
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL/BLU WIRE
YEL/BRN WIRE
Go to component -> 2.0l vin x, transmission circuit (3 of 3) -> TRANSMISSION CONTROL SOLENOID VALVE 10
