Chevrolet Malibu IX facelift (2018-2024) serial data 2 serial data bus 12 Wiring diagram
This page shows the only wiring diagram for the component.serial data 2 serial data bus 12, which is found in the car Chevrolet Malibu IX facelift (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram serial data 2 serial data bus 12 (1 of 1)
ACCESSORY WAKEUP SERIAL DATA
BATT POSITIVE VOLT
BLK/BRN WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
CLUTCH A CTRL
CLUTCH B CTRL
CLUTCH C CTRL
CLUTCH D CTRL
CLUTCH E CTRL
COMPUTER DATA LINES SYSTEM
DRIVER INFORMATION CENTER DISPLAY
GRN/BLK WIRE
GRN/GRY WIRE
GRN/VIO WIRE
GRN/YEL WIRE
GRY WIRE
GRY/BLK WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/GRN WIRE
HI SPD GMLAN SERIAL DATA (-) (1)
HOT AT ALL TIMES
HOT W/ IGNITION MAIN RELAY ENERGIZED
IGN MODE SW MODE CTRL
IN SPD SIG
INSTRUMENT CLUSTER
LOGIC
OUT SPD SIG
RED/GRN WIRE
RUN/CRANK IGNITION 1 VOLT
SERIAL DATA 2 SERIAL DATA BUS 12
SIG GND
TCC/CLUTCH SOL CTRL
TRANS CLUTCH F CTRL
TRANS CLUTCH G CTRL
TRANS CLUTCH H CTRL
TRANS HI SIDE DRV 1 SIG
TRANS HI SIDE DRV 2 SIG
TRANS INTERMEDIATE SPD SIG
TRANS LEVEL TEMP SENS
TRANS OIL TEMP SENS LO REF
TRANS OIL TEMP SENS SIG
TRANSMISSION CONTROL MODULE (IN TRANSMISSION)
TRANSMISSION INPUT SHAFT SPEED SENSOR
TRANSMISSION INPUT/ INTERMEDIATE SHAFT SPEED SENSOR
TRANSMISSION INTERMEDIATE SHAFT SPEED SENSOR
UNDERHOOD FUSE BLOCK
VIO WIRE
VIO/BLK WIRE
VIO/YEL WIRE
WHT WIRE
WHT/BLU WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/GRN WIRE
Go to component -> 2.0l vin x, transmission circuit (1 of 3) -> SERIAL DATA 2 SERIAL DATA BUS 12
