Chevrolet Malibu IX facelift (2018-2024) selection switch Wiring diagram
This page shows the only wiring diagram for the component.selection switch, which is found in the car Chevrolet Malibu IX facelift (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram selection switch (1 of 1)
BATT POS VOLT
BLK WIRE
BLK/BRN WIRE
BLU/WHT WIRE
BRN/BLK WIRE
BRN/YEL WIRE
COMMON CTRL
COMPUTER DATA LINES SYSTEM
DATA BUS 8
DEFOGGER SYSTEM
DOWN
DRIVER OUTSIDE REAR VIEW MIRROR GLASS
DRIVER OUTSIDE REAR VIEW MIRROR MOTOR
DRIVER OUTSIDE REAR- VIEW MIRROR
DRIVER SIDE OBJECT DETECTION INDICATOR
DRIVER WINDOW/ OUTSIDE REAR VIEW MIRROR SWITCH
EXTERIOR LIGHTS, NAVIGATION SYSTEMS
FOLD
GRN/WHT WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
LEFT
LEFT (-) RIGHT (+) SIG
LEFT TURN SIGNAL REPEATER LAMP
LOGIC
LOW REF
NAVIGATION SYSTEM
RED/BLU WIRE
RH (+) LEFT (-) CTRL
RIGHT
SELECTION SWITCH
UNDERHOOD FUSE BLOCK
UNFOLD
UP (+) DOWN (-) CTRL
UP DOWN SIG
VIO/BLU WIRE
VIO/RED WIRE
WHT/YEL WIRE
YEL/BRN WIRE
Go to component -> Memory mirrors circuit (1 of 2) -> SELECTION SWITCH
