Chevrolet Malibu IX facelift (2018-2024) right rear side impact sensor Wiring diagram
This page shows the only wiring diagram for the component.right rear side impact sensor, which is found in the car Chevrolet Malibu IX facelift (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear side impact sensor (1 of 1)
AIR BAG IND
AUTOMATIC LOCKING
BLK WIRE
BLK/ORG WIRE
BLU/ORG WIRE
BRN/ORG WIRE
BUS 12
COMPUTER DATA
COMPUTER DATA LINES SYSTEM
CRANK
DATA
DATA 2 (+)
DRIVER INFORMATION CENTER DISPLAY
DRIVER SEAT BELT RETRACTOR PRETENSIONER
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GROUND
GRY/GRN WIRE
GRY/ORG WIRE
HOT W/ IGNITION MAIN RELAY ENERGIZED
IGN 1
INSTRUMENT CLUSTER
LEFT FRONT SIDE IMPACT SENSOR
LEFT REAR SIDE IMPACT SENSOR
LEFT ROOF RAIL AIR BAG
LINES SYSTEM
LOGIC
LOW SPD GMLAN
ORG/BLU WIRE
ORG/BRN WIRE
ORG/GRN WIRE
ORG/GRY WIRE
ORG/VIO WIRE
ORG/WHT WIRE
ORG/YEL WIRE
PASSENGER PRESENCE MODULE
PASSENGER SEAT BELT RETRACTOR PRETENSIONER
PASSENGER SEAT BELT TENSION SENSOR
PASSENGER SEAT SIDE AIR BAG
RED WIRE
RED/BRN WIRE
RETRACTOR SW LOW REF
RETRACTOR SW SIG
RIGHT FRONT SIDE IMPACT SENSOR
RIGHT REAR SIDE IMPACT SENSOR
RUN/
SEAT BELT IND
SERIAL
SERIAL DATA
SHORTING BAR
UNDERHOOD FUSE BLOCK
VIO WIRE
VIO/GRY WIRE
VIO/ORG WIRE
WHT/ORG WIRE
Go to component -> Supplemental restraints circuit (2 of 3) -> RIGHT REAR SIDE IMPACT SENSOR
