Chevrolet Malibu IX facelift (2018-2024) mobile device wireless charger module Wiring diagrams
This page contains all the electrical diagrams for the component. mobile device wireless charger module, in which he is found in the car Chevrolet Malibu IX facelift (2018-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram mobile device wireless charger module (1 of 2)
2.0L
A/C COMPRESSOR
A/C COMPRESSOR CLUTCH
ACCESSORY DC/ AC POWER INVERTER MODULE
AUTOMATIC TRANSMISSION ASSEMBLY
AUXILIARY AUDIO INPUT
AUXILIARY HEATER COOLANT PUMP
BATTERY
BATTERY CURRENT SENSOR
BATTERY SENSOR MODULE
BLK WIRE
BLK/WHT WIRE
BLOWER MOTOR
BODY CONTROL MODULE
CENTER CONSOLE ACCESSORY POWER RECEPTACLE
ELECTRIC/ AUXILIARY TRANSMISSION FLUID PUMP
ENGINE CONTROL MODULE
ENGINE OIL LEVEL SWITCH
INSTRUMENT PANEL ACCESSORY POWER RECEPTACLE
LOGIC
MOBILE DEVICE WIRELESS CHARGER MODULE
MULTI-FUNCTION INTAKE AIR SENSOR
RADIO
STARTER RELAY
TELEMATICS COMMUNICATION INTERFACE CONTROL MODULE
TRANSMISSION CONTROL MODULE
USB RECEPTACLE
W/ ONSTAR
W/ START/ STOP SYSTEM
W/ START/STOP SYSTEM
W/O START STOP SYSTEM
Go to component -> Ground distribution circuit (3 of 6) -> MOBILE DEVICE WIRELESS CHARGER MODULE
Wiring diagram mobile device wireless charger module (2 of 2)
BATT POSITIVE VOLT
BLK WIRE
BLU WIRE
BLU/BRN WIRE
BODY CONTROL MODULE
BRN WIRE
CENTER CONSOLE ACCESSORY POWER RECEPTACLE
CHARGE IND CTRL
DC TO AC
FAULT IND CTRL
FSD CTRL
GRN WIRE
GRY WIRE
INSTRUMENT PANEL ACCESSORY POWER RECEPTACLE
INSTRUMENT PANEL FUSE BLOCK
INVERTER CTRL
KEYLESS ENTRY CONTROL MODULE
LOGIC
LOW REFERENCE
MOBILE DEVICE WIRELESS CHARGER MODULE
NCA WIRE
RED WIRE
RED/GRN WIRE
RETAINED ACCESSORY POWER RELAY
TRANSMISSION SHIFT LEVER POSITION INDICATOR
VIO WIRE
Go to component -> Power distribution circuit (4 of 7) -> MOBILE DEVICE WIRELESS CHARGER MODULE
