Chevrolet Malibu IX facelift (2018-2024) left rear seat heating switch Wiring diagram
This page shows the only wiring diagram for the component.left rear seat heating switch, which is found in the car Chevrolet Malibu IX facelift (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear seat heating switch (1 of 1)
BLK WIRE
DRIVER BACK SEAT BLOWER MOTOR
DRIVER CUSHION SEAT BLOWER MOTOR
DRIVER DOOR HANDLE FLOOD LAMP
DRIVER DOOR LATCH ASSEMBLY
DRIVER DOOR POCKET FLOOD LAMP
DRIVER EXTERIOR DOOR HANDLE ASSEMBLY
DRIVER EXTERIOR DOOR HANDLE SWITCH
DRIVER OUTSIDE REAR VIEW MIRROR GLASS
DRIVER OUTSIDE REAR- VIEW MIRROR
DRIVER SEAT ADJUSTER SWITCH
DRIVER SEAT LUMBAR SUPPORT SWITCH
DRIVER WINDOW MOTOR
DRIVER WINDOW/ OUTSIDE REAR VIEW MIRROR SWITCH
INSIDE REAR VIEW MIRROR
LEFT REAR DOOR LATCH ASSEMBLY
LEFT REAR SEAT HEATING SWITCH
LEFT REAR WINDOW SWITCH
LOGIC
PASSENGER DOOR HANDLE FLOOD LAMP
PASSENGER DOOR LATCH ASSEMBLY
PASSENGER DOOR LOCK SWITCH
PASSENGER EXTERIOR DOOR HANDLE ASSEMBLY
PASSENGER EXTERIOR DOOR HANDLE SWITCH
PASSENGER OUTSIDE REAR VIEW MIRROR
PASSENGER OUTSIDE REAR VIEW MIRROR GLASS
RIGHT REAR DOOR LATCH ASSEMBLY
RIGHT REAR SEAT HEATING SWITCH
RIGHT TURN SIGNAL REPEATER LAMP
SEAT MEMORY CONTROL MODULE
W/ 2 WAY LUMBAR
W/ EXPRESS UP/DOWN
W/ MEMORY
W/O 2 WAY LUMBAR
W/O EXPRESS UP/DOWN
WHT/BLK WIRE
WINDSHIELD FRONT VIEW CAMERA
Go to component -> Ground distribution circuit (5 of 6) -> LEFT REAR SEAT HEATING SWITCH
