Chevrolet Malibu IX facelift (2018-2024) left outer front parking assist sensor Wiring diagram

BATTERY POS VOLT BLK WIRE BLK/BLU WIRE BLK/GRY WIRE BLU WIRE BLU/YEL WIRE BODY CONTROL MODULE BRN WIRE BRN/WHT WIRE CENTER CONSOLE MULTI-FUNCTION SWITCH COMM ENABLE COMPUTER DATA LINES SYSTEM DRIVER INFORMATION CENTER DISPLAY FRONT PARKING AID DISPLAY CTRL FRONT PARKING LEFT CORNER SENS FRONT PARKING LEFT MID SENS FRONT PARKING RIGHT CORNER SENS FRONT PARKING RIGHT MID SENS GRN WIRE GRN/YEL WIRE GRY WIRE GRY/GRN WIRE HI SPD GMLAN SERIAL DATA (+) 2 GROUND HI SPD GMLAN SERIAL DATA (-) (2) HOT AT ALL TIMES INSTRUMENT CLUSTER INSTRUMENT PANEL FUSE BLOCK LEFT FRONT SIDE PARKING ASSIST SENSOR LEFT MIDDLE FRONT PARKING ASSIST SENSOR LEFT MIDDLE REAR PARKING ASSIST SENSOR LEFT OUTER FRONT PARKING ASSIST SENSOR LEFT OUTER REAR PARKING ASSIST SENSOR LEFT REAR SIDE PARKING ASSIST SENSOR LF SUPPLEMENTAL OBJECT SENS SIG LOGIC LOW REFERENCE LOW SPD GMLAN SERIAL DATA LOW SPD GMLAN SERIAL DATA 2 LR CORNER OBJECT SENS SIG LR MIDDLE OBJECT SENS SIG LR SUPPLEMENTAL OBJECT SENS SIG OBJECT SENS CTRL PARALLEL PARKING ASSIST SW PARK ASSIST DISABLED SW PARKING ASSIST CONTROL MODULE (RIGHT SIDE OF LUGGAGE COMPT) PARKING ASSIST IND POWER SUPPLY TRANSFORMER (UNDER CENTER CONSOLE) REAR PARK ASSIST DISABLE SIGNAL REAR PARK ASSIST LED DISABLE SIG RED WIRE RED/GRN WIRE RED/GRY WIRE RED/YEL WIRE RF SUPPLEMENTAL OBJECT SENS SIG RIGHT FRONT SIDE PARKING ASSIST SENSOR RIGHT MIDDLE FRONT PARKING ASSIST SENSOR RIGHT MIDDLE REAR PARKING ASSIST SENSOR RIGHT OUTER FRONT PARKING ASSIST SENSOR RIGHT OUTER REAR PARKING ASSIST SENSOR RIGHT REAR SIDE PARKING ASSIST SENSOR RR CORNER OBJECT SENS SIG RR MIDDLE OBJECT SENS SIG RR SUPPLEMENTAL OBJECT SENS SIG SPLY VOLT SW SIG UNDERHOOD FUSE BLOCK VIO/GRY WIRE VIO/WHT WIRE W/ BRAKE PREFILL INTEGRATED BRAKE ASSIST W/O BRAKE PREFILL, INTEGRATED BRAKE ASSIST W/ START/STOP SYSTEM W/O START/STOP SYSTEM WHT WIRE WHT/BLU WIRE WHT/GRY WIRE YEL WIRE YEL/BLU WIRE YEL/GRY WIRE YEL/VIO WIRE YEL/WHT WIRE
