Chevrolet Malibu IX facelift (2018-2024) drv side object detection led sig 1 Wiring diagram
This page shows the only wiring diagram for the component.drv side object detection led sig 1, which is found in the car Chevrolet Malibu IX facelift (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram drv side object detection led sig 1 (1 of 1)
BATT POS VOLT
BLK WIRE
COMPUTER DATA LINES SYSTEM
DRIVER OUTSIDE REAR VIEW MIRROR GLASS
DRIVER OUTSIDE REAR- VIEW MIRROR
DRIVER SIDE OBJECT DETECTION INDICATOR
DRV SIDE OBJECT DETECTION LED SIG 1
GRN WIRE
GROUND
GRY WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL FUSE BLOCK
LEFT SIDE OBJECT SENSOR MODULE
LOW SPEED GMLAN SERIAL DATA
PASS SIDE OBJECT DETECTION LED SIG (1)
PASSENGER OUTSIDE REAR VIEW MIRROR
PASSENGER OUTSIDE REAR VIEW MIRROR GLASS
PASSENGER SIDE OBJECT DETECTION INDICATOR
POWER SUPPLY TRANSFORMER
RED/GRN WIRE
RED/GRY WIRE
RED/YEL WIRE
RIGHT SIDE OBJECT SENSOR MODULE
SPLY VOLT 1
UNDERHOOD FUSE BLOCK
W/ START/STOP SYSTEM
W/O START/STOP SYSTEM
Go to component -> Blind spot monitoring circuit -> DRV SIDE OBJECT DETECTION LED SIG 1
