Chevrolet Malibu IX facelift (2018-2024) drv pwr seat frt vert mtr dwn Wiring diagram
This page shows the only wiring diagram for the component.drv pwr seat frt vert mtr dwn, which is found in the car Chevrolet Malibu IX facelift (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram drv pwr seat frt vert mtr dwn (1 of 1)
BATT POS VOLT
BLU/VIO WIRE
BLU/YEL WIRE
BRN/WHT WIRE
DRIVER SEAT FRONT VERTICAL MOTOR
DRIVER SEAT HORIZONTAL MOTOR
DRIVER SEAT REAR VERTICAL MOTOR
DRIVER SEAT RECLINE MOTOR
DRV PWR SEAT FRT VERT MTR DWN
DRV PWR SEAT FRT VERT MTR UP
DRV PWR SEAT HORIZ MTR FWD
DRV PWR SEAT HORIZ MTR RWD
DRV PWR SEAT RECLINE MTR FWD
DRV PWR SEAT RECLINE MTR RWD
DRV PWR SEAT RR VERT MTR DWN
DRV PWR SEAT RR VERT MTR UP
GRN WIRE
GRN/BRN WIRE
GRN/YEL WIRE
GRY/BLU WIRE
GRY/GRN WIRE
HOT AT ALL TIMES
RED/BLU WIRE
RED/VIO WIRE
SEAT MEMORY CONTROL MODULE (BELOW DRIVER'S SEAT)
UNDERHOOD FUSE BLOCK
WHT/BLK WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Memory seat circuit (2 of 2) -> DRV PWR SEAT FRT VERT MTR DWN
