Chevrolet Malibu IX facelift (2018-2024) dfi hi volt ctrl cylinder 2 Wiring diagram
This page shows the only wiring diagram for the component.dfi hi volt ctrl cylinder 2, which is found in the car Chevrolet Malibu IX facelift (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram dfi hi volt ctrl cylinder 2 (1 of 1)
ACTIVE GRILLE AIR SHUTTER ACTUATOR 1
ACTIVE GRILLE AIR SHUTTER ACTUATOR 2
AERO
BATTERY SENSOR MODULE
BLK WIRE
BLK/BRN WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRY WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
CTRL
DATA 2 (+)
DFI HI VOLT CTRL CYLINDER 1
DFI HI VOLT CTRL CYLINDER 2
DFI HI VOLT CTRL CYLINDER 3
DFI HI VOLT CTRL CYLINDER 4
DFI HI VOLT SPLY CYLINDER 1
DFI HI VOLT SPLY CYLINDER 2
DFI HI VOLT SPLY CYLINDER 3
DFI HI VOLT SPLY CYLINDER 4
DRIVER INFORMATION CENTER DISPLAY
DUTY CYCLE SIG
ECT SENS SIG
ENGINE CONTROL MODULE
ENGINE COOLANT TEMPERATURE GAUGE
ENGINE COOLANT TEMPERATURE IND
ENGINE OIL IND
FRP SENS SIG
FUEL GAUGE
FUEL IND
FUEL INJECTOR 1
FUEL INJECTOR 2
FUEL INJECTOR 3
FUEL INJECTOR 4
FUEL LINE PRESS SENS SIG
GMLAN
GRN WIRE
GRN/GRY WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLU WIRE
GRY/GRN WIRE
GRY/RED WIRE
IGN 1
IND
INSTRUMENT CLUSTER
LOGIC
LOW SPD
MALFUNCTION IND
SERIAL
SIG GND
STARTING/ CHARGING SYSTEM
THRO POS SENS 5 VOLT REF
VIO/BLU WIRE
VOLT
W/ START/STOP
W/ UPPER, LOWER ACTIVE FRONT GRILLE SHUTTERS
WHT/BLU WIRE
WHT/RED WIRE
YEL/RED WIRE
Go to component -> Wiring diagram engine performance 1.5l vin t (5 of 7) -> DFI HI VOLT CTRL CYLINDER 2
