Chevrolet Malibu IX facelift (2018-2024) ambient light/ sunload sensor logic Wiring diagram
This page shows the only wiring diagram for the component.ambient light/ sunload sensor logic, which is found in the car Chevrolet Malibu IX facelift (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ambient light/ sunload sensor logic (1 of 1)
AMBIENT LIGHT/ SUNLOAD SENSOR LOGIC
AUDIO AMPLIFIER
BLK WIRE
BODY CONTROL MODULE
BRN WIRE
COLLISION ALERT INDICATORS
DATA LINK CONNECTOR
ELECTRONIC BRAKE CONTROL MODULE
FRONT SEAT HEATING CONTROL MODULE
HEADLAMP SWITCH
HVAC CONTROL MODULE
IGNITION MODE SWITCH
INSTRUMENT CLUSTER LOGIC
KEYLESS ENTRY CONTROL MODULE
PASSENGER BACK SEAT BLOWER MOTOR
PASSENGER CUSHION SEAT BLOWER MOTOR
PASSENGER SEAT ADJUSTER SWITCH
PASSENGER SEAT LUMBAR SUPPORT SWITCH
PASSENGER WINDOW SWITCH LOGIC
POWER SUPPLY TRANSFORMER
REAR SEAT HEATING CONTROL MODULE
RIGHT REAR WINDOW SWITCH LOGIC
SERIAL DATA GATEWAY MODULE
TRANSMISSION SHIFT LEVER POSITION INDICATOR LOGIC
TURN SIGNAL/ MULTI-FUNCTION SWITCH
UNDERHOOD FUSE BLOCK
W/ 4 WAY SEAT ADJUSTER
W/ MEMORY
W/ POWER OPERATED PARKING BRAKE
W/ START/ STOP SYSTEM
W/O 4 WAY SEAT ADJUSTER
W/O MEMORY
W/O ONSTAR
WINDSHIELD WIPER MOTOR
WINDSHIELD WIPER RELAY
WINDSHIELD WIPER SPEED CONTROL RELAY
YEL WIRE
YEL/BRN WIRE
Go to component -> Ground distribution circuit (4 of 6) -> AMBIENT LIGHT/ SUNLOAD SENSOR LOGIC
