Chevrolet Malibu IX (2015-2018) right rear side object sensor Wiring diagram

BATTERY POS VOLT BLK WIRE BLK/BLU WIRE BLK/GRY WIRE BLU WIRE BLU/YEL WIRE BODY CONTROL MODULE BRN WIRE BRN/WHT WIRE CENTER CONSOLE MULTI-FUNCTION SWITCH COMM ENABLE COMPUTER DATA LINES SYSTEM DC DC BATT 1 FUSE DRIVER INFORMATION CENTER DISPLAY FRONT PARKING AID DISPLAY CTRL FRONT PARKING LEFT CORNER SENS FRONT PARKING LEFT MID SENS FRONT PARKING RIGHT CORNER SENS FRONT PARKING RIGHT MID SENS FUSE 40 GRN WIRE GRN/YEL WIRE GROUND GRY WIRE HI SPD GMLAN SERIAL DATA (-) (2) HOT AT ALL TIMES INSTRUMENT CLUSTER INSTRUMENT PANEL FUSE BLOCK LEFT FRONT SIDE OBJECT SENSOR LEFT MIDDLE FRONT OBJECT SENSOR LEFT MIDDLE REAR OBJECT SENSOR LEFT OUTER FRONT OBJECT SENSOR LEFT OUTER REAR OBJECT SENSOR LEFT REAR SIDE OBJECT SENSOR LF SUPPLEMENTAL OBJECT SENS SIG LOGIC LOW REFERENCE LOW SPD GMLAN SERIAL DATA LR CORNER OBJECT SENS SIG LR MIDDLE OBJECT SENS SIG LR SUPPLEMENTAL OBJECT SENS SIG OBJECT SENS CTRL PARKING ASSIST CONTROL MODULE POWER SUPPLY TRANSFORMER (UNDER CENTER CONSOLE) REAR PARK ASSIST DISABLE SIGNAL REAR PARK ASSIST LED DISABLE SIG RED WIRE RED/GRN WIRE RED/GRY WIRE RED/YEL WIRE RF SUPPLEMENTAL OBJECT SENS SIG RIGHT FRONT SIDE OBJECT SENSOR RIGHT MIDDLE FRONT OBJECT SENSOR RIGHT MIDDLE REAR OBJECT SENSOR RIGHT OUTER FRONT OBJECT SENSOR RIGHT OUTER REAR OBJECT SENSOR RIGHT REAR SIDE OBJECT SENSOR RR CORNER OBJECT SENS SIG RR MIDDLE OBJECT SENS SIG RR SUPPLEMENTAL OBJECT SENS SIG SPLY VOLT SW SIG UNDERHOOD FUSE BLOCK VIO/GRY WIRE VIO/WHT WIRE W/ BRAKE PREFILL INTEGRATED BRAKE ASSIST W/ OBSTACLE DETECTION ENHANCED SIDE ACTIVE SAFETY W/ START/STOP SYSTEM W/O START/STOP SYSTEM W/O BRAKE PREFILL INTEGRATED BRAKE ASSIST W/O OBSTACLE DETECTION ENHANCED SIDE ACTIVE SAFETY WHT WIRE WHT/BLU WIRE WHT/GRY WIRE WHT/YEL WIRE YEL WIRE YEL/BLU WIRE YEL/GRY WIRE YEL/VIO WIRE YEL/WHT WIRE
