Chevrolet Malibu IX (2015-2018) rf turn sig lp Wiring diagram
This page shows the only wiring diagram for the component.rf turn sig lp, which is found in the car Chevrolet Malibu IX (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rf turn sig lp (1 of 1)
AUTO PARK
BATT POS VOLT
BCM 6/ BCM 7 FUSE
BLK WIRE
BLK/BRN WIRE
BLU WIRE
BLU/BRN WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BODY CONTROL MODULE
BRAKE APPLY SENS CTRL
BRAKE APPLY SENS SIG
BRN/GRN WIRE
BRN/YEL WIRE
CENTER HIGH MOUNTED STOP LAMP
COMPUTER DATA LINES SYSTEM
FUSE 20
FUSE 21
FUSE 41
FUSE 8
GMLAN SERIAL DATA - 1
GRN WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
GRY/BLU WIRE
HAZARD LED DIMMING SIG
HAZARD SW SIG
HAZARD WARNING SWITCH
HDLP SW HDLP OFF SIG CTRL
HEADLAMP SWITCH
HOT AT ALL TIMES
INSTRUMENT PANEL FUSE BLOCK
LEFT
LEFT LICENSE PLATE LAMP
LEFT TURN SIG
LF DRL CTRL
LF TURN SIG LP
LH PARK LP CTRL
LR STOP/TURN LP CTRL
OFF HEAD
PARK BRAKE SWITCH
PARK BRK SW SIG
PARK LP RLY CTRL
PARK LP SIG
POWER SUPPLY TRANSFORMER
REAR LICENSE LP CTRL
REAR TURN LP FEEDBACK CTRL
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/WHT WIRE
RED/YEL WIRE
RF DRL CTRL
RF TURN SIG LP
RH PARK LP CTRL 11 13 COIL CTRL
RIGHT
RIGHT LICENSE PLATE LAMP
RIGHT TURN SIG
RR STOP/TURN LP CTRL
RR TURN LP FEEDBACK SIG
SENS LO REF
SPLY VOLT
TURN SIGNAL/ MULTI-FUNCTION SWITCH
UNDERHOOD FUSE BLOCK
VIO WIRE
VIO/GRY WIRE
VIO/WHT WIRE
W/ PARKING ASSIST
W/ START/STOP
W/O START/STOP
WHT WIRE
WHT/BLK WIRE
WHT/VIO WIRE
YEL/BLU WIRE
Go to component -> Exterior lamps circuit (1 of 4) -> RF TURN SIG LP
