Chevrolet Malibu IX (2015-2018) passive start sw 2 low ref Wiring diagram
This page shows the only wiring diagram for the component.passive start sw 2 low ref, which is found in the car Chevrolet Malibu IX (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passive start sw 2 low ref (1 of 1)
AUTOMATIC TRANSMISSION ASSEMBLY
BATTERY POSITIVE VOLT
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BODY CONTROL MODULE (BEHIND LEFT END OF DASH)
COMPUTER DATA LINES SYSTEM
CONTROL SOLENOID VALVE ASSEMBLY
DRIVER INFORMATION CENTER DISPLAY
ENGINE CONTROL MODULE (TOP OF TRANSMISSION)
ENGINE START/STOP
GMLAN SERIAL DATA
GRN WIRE
GRY WIRE
HI SPD GMLAN SERIAL DATA (-) (1)
HIGH SPEED GMLAN SERIAL DATA (-) (1)
IGN MODE SW MODE VOLT
IGNITION MODE SWITCH
INSTRUMENT CLUSTER
KEYLESS ENTRY CONTROL MODULE
LOGIC
LOW SPEED
PASSIVE START SW 2 LOW REF
PASSIVE START SW SIG 2
PUSH BUTTON START CHALLENGE ACTIVE SIG
RED/WHT WIRE
RUN/CRANK IGN 1 VOLT
SIG GND
STARTER ENABLE RELAY CTRL
STARTER PINION SOL RELAY CTRL
TRANSMISSION CONTROL MODULE
TRANSMISSION INTERNAL MODE SWITCH
TRANSMISSION PARK/ NEUTRAL SIG 1
VIO WIRE
VIO/GRN WIRE
WHT WIRE
WHT/GRY WIRE
YEL WIRE
YEL/BLK WIRE
YEL/VIO WIRE
Go to component -> Starting circuit, w/ start-stop system (2 of 2) -> PASSIVE START SW 2 LOW REF
