Chevrolet Malibu IX (2015-2018) network serial data bus 3 Wiring diagram

12 VOLT ACCESSORY VOL ANTI-THEFT SYSTEM BACKUP LP SPLY VOL BATT POS VOL BATTERY FUSE BLOCK BCM 6/ BCM 7 FUSE BLK WIRE BLU WIRE BLU/BRN WIRE BLU/VIO WIRE BODY CONTROL MODULE (BEHIND LEFT END OF DASH) BRN WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/YEL WIRE COMMUNICATION ENABLE COMPUTER DATA LINES SYSTEM COURTESY LP SW SIG CRUISE CONTROL SYSTEM CRUISE CTRL CURRENT SENS CTRL CURRENT SENS SIG DC DC BATT 1 FUSE DIMMING CTRL DOOR LOCKS, ANTI-THEFT SYSTEMS DOOR LOCKS, INTERIOR LIGHTS SYSTEMS DR LOCK ACTUATOR LOCK CTRL DR LOCK ACTUATOR LOCK CTRL 2 DR LOCK ACTUATOR UNLOCK CTRL DRV DR LK SW LK CTRL DRV DR LK SW UNLK CTRL FEEDBACK CTRL FUSE 4 GAP UP/DOWN SW SIG GRN WIRE GRN/BRN WIRE GRN/GRY WIRE GRN/VIO WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/GRN WIRE GRY/VIO WIRE HDLP DIMMER SW HI BEAM SIG HDLP SW FLASH TO PASS SIG HEADLIGHTS SYSTEM HIGH SPD GMLAN SERIAL DATA HOOD AJAR SW SIG HORN SW SIG HORNS SYSTEM HOT AT ALL TIMES IGNITION VOL IMMOBILIZER POWER IMMOBILIZER RTN INADVERTENT POWER CONTROL INTERCONNECT NETWORK 11 INTR LP CTRL INTR LP DEFEAT SW SIG LED AMBIENT LH HDLP LOW BEAM SPLY VOL LH PARK LP STRL LH TURN SIG LID LP CTRL LIFT GATE AJAR SWITCH SIG (1) LOW REF LR DR LK MTR STATUS LR STOP/TURN LP CTRL NAVIGATION SYSTEM NETWORK SERIAL DATA BUS 1 NETWORK SERIAL DATA BUS 2 NETWORK SERIAL DATA BUS 3 ON BATTERY) OPEN SIG PARK LOCK SOLENOID CONTROL PASS DR LK SW LK CTRL PASS DR LK SW UNLK CTRL POWER DISTRIBUTION SYSTEM PUSH BUTTON START REAR LICENSE LP SUPPLY VOL RED WIRE RED/GRY WIRE RED/WHT WIRE RF DRL CTRL RH HDLP LOW BEAM SPLY VOL RH PARK LP CTRL RH TURN SIG RR DR LK MTR STATUS RR STOP/TURN LP CTRL RR TURN LP FEEDBACK SIG RR TURN SIG LP RUN/CRANK RELAY COIL CTRL SHIFT INTERLOCK SYSTEM SHIFT INTERLOCK, TRANSMISSIONS SYSTEMS SHIFT POS SIG STARTING/CHARGING SYSTEM STARTING/CHARGING, DOOR LOCKS, ANTI-THEFT SYSTEMS STOP LAMP RLY COIL SPLY VOL TRUNK, TAILGATE, FUEL DOORS SYSTEM UNDERHOOD FUSE BLOCK VIO WIRE VIO/BLK WIRE VIO/GRY WIRE VIO/WHT WIRE VIO/YEL WIRE WASHER SW SIG WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/RED WIRE WHT/VIO WIRE WHT/YEL WIRE WINDSHIELD WASHER RLY CTRL WIPER MTR PARK SW SIG WIPER RLY SUPPLY VOLTAGE WIPER SW HI SIG WIPER SW LOW SIG WIPER/WASHER SYSTEM YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/VIO WIRE
