Chevrolet Malibu IX (2015-2018) hybrid/ev battery interface control module 6 Wiring diagram
This page shows the only wiring diagram for the component.hybrid/ev battery interface control module 6, which is found in the car Chevrolet Malibu IX (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hybrid/ev battery interface control module 6 (1 of 1)
BLK WIRE
BLU WIRE
FROM HYBRID/EV BATTERY INTERFACE CONTROL MODULE 5 (DIAGRAM 5 OF 7)
FROM HYBRID/EV BATTERY SECTION 5 (DIAGRAM 5 OF 7)
GRN WIRE
HYBRID/EV BATTERY INTERFACE CONTROL MODULE 6
HYBRID/EV BATTERY INTERFACE CONTROL MODULE 7
HYBRID/EV BATTERY INTERFACE CONTROL MODULE 8
HYBRID/EV BATTERY PACK (BETWEEN REAR WHEELWELLS)
HYBRID/EV BATTERY SECTION 6
HYBRID/EV BATTERY SECTION 7
HYBRID/EV BATTERY SECTION 8
HYBRID/EV BATTERY TEMPERATURE SENSOR 11
HYBRID/EV BATTERY TEMPERATURE SENSOR 12
HYBRID/EV BATTERY TEMPERATURE SENSOR 13
HYBRID/EV BATTERY TEMPERATURE SENSOR 14
HYBRID/EV BATTERY TEMPERATURE SENSOR 15
HYBRID/EV BATTERY TEMPERATURE SENSOR 16
NCA WIRE
ORG/ WIRE
TO HYBRID/EV BATTERY CONTACTOR ASSEMBLY (DIAGRAM 7 OF 7)
VIO WIRE
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/VIO WIRE
Go to component -> Wiring diagram engine performance 1.8l vin u, hybrid system circuit (6 of 7) -> HYBRID/EV BATTERY INTERFACE CONTROL MODULE 6
