Chevrolet Malibu IX (2015-2018) frt object sens ctrl 2 Wiring diagram
This page shows the only wiring diagram for the component.frt object sens ctrl 2, which is found in the car Chevrolet Malibu IX (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram frt object sens ctrl 2 (1 of 1)
ACTIVE SAFETY CONTROL MODULE
BATT POS
BATT POS VOLT
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/VIO WIRE
BLU/YEL WIRE
COMPUTER DATA LINES SYSTEM
DATA COMM ENABLE GMLAN SERIAL DATA (-) 1
DC DC BATT 1 FUSE
DRIVER INFORMATION CENTER DISPLAY
FRT OBJECT SENS CTRL 2
FUSE 40
GMLAN SERIAL DATA (+) 4
GMLAN SERIAL DATA - 1
GMLAN SERIAL DATA 2
GRN WIRE
GRY WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER
INSTRUMENT PANEL FUSE BLOCK
LANE DEPARTURE WARNING IND
LANE DEPARTURE WARNING IND CTRL
LEFT STEERING WHEEL CONTROLS SWITCH
LOGIC
LONG RANGE RADAR SENSOR MODULE
LOW SPD GMLAN SERIAL DATA
POWER SUPPLY TRANSFORMER
RED WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/YEL WIRE
RIGHT STEERING WHEEL CONTROLS SWITCH
SIG GND
SPLY VOLT 1
STEERING WHEEL AIR BAG COIL
UNDERHOOD FUSE BLOCK
VOLT
W/ START/STOP SYSTEM
W/O START/STOP SYSTEM
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WINDSHIELD FRONT VIEW CAMERA
YEL WIRE
Go to component -> Collision avoidance circuit -> FRT OBJECT SENS CTRL 2
