Chevrolet Malibu IX (2015-2018) forward collision alert warning switch Wiring diagram
This page shows the only wiring diagram for the component.forward collision alert warning switch, which is found in the car Chevrolet Malibu IX (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram forward collision alert warning switch (1 of 1)
12 VOLT REF
ALERT LED CTRL
BATT POS VOLT
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
COLLISION ALERT INDICATORS
COMM ENABLE
COMPUTER DATA LINES SYSTEM
DC DC BATT 1 FUSE
DIMMING CTRL
DRIVER INFORMATION CENTER DISPLAY
FORWARD COLLISION ALERT WARNING SWITCH
FUSE 40
GRN WIRE
GROUND
GRY WIRE
GRY/GRN WIRE
HI SPD GMLAN SERIAL DATA (-) (1)
HOT AT ALL TIMES
HOT W/ IGNITION MAIN RELAY ENERGIZED
IGN 1 VOLT
INSTRUMENT CLUSTER
INSTRUMENT PANEL FUSE BLOCK
IP BODY IGN FUSE
LANE DEPARTURE WARNING DISABLE SWITCH
LANE DEPARTURE WARNING IND
LANE DEPARTURE WARNING IND CTRL
LEFT STEERING WHEEL CONTROLS SWITCH
LO SPD GMLAN SERIAL DATA
LOGIC
POWER SUPPLY TRANSFORMER
RED/GRN WIRE
RED/GRY WIRE
RED/YEL WIRE
SPLY VOLT 1
STEERING WHEEL AIR BAG COIL
UNDERHOOD FUSE BLOCK
UP/DOWN SW SIG
VIO/GRY WIRE
W/ START/STOP SYSTEM
W/O START/STOP SYSTEM
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
WINDSHIELD FRONT VIEW CAMERA
Go to component -> Lane departure warning circuit, w/o brake prefill & intelligent brake assist -> FORWARD COLLISION ALERT WARNING SWITCH
