Chevrolet Malibu IX (2015-2018) cool mtr ctrl Wiring diagrams
This page contains all the electrical diagrams for the component. cool mtr ctrl, in which he is found in the car Chevrolet Malibu IX (2015-2018). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
cool mtr ctrl wiring diagram (1 of 2)
A/C LOW SIDE PRESSURE SENSOR
BATT POS VOLT
BLK WIRE
BLK/GRN WIRE
BLK/YEL WIRE
BLU WIRE
BLU/RED WIRE
BRN/BLU WIRE
BRN/GRN WIRE
COMPUTER DATA LINES SYSTEM
COOL FAN CTRL
COOL MTR CTRL
ENGINE COOLANT THERMOSTAT HEATER
FEEDBACK SIG
GRN/VIO WIRE
GROUND
HOT AT ALL TIMES
HYBRID/EV BATTERY PACK (BETWEEN REAR WHEELWELLS)
HYBRID/EV ELECTRONICS COOLANT TEMPERATURE SENSOR
HYBRID/EV POWERTRAIN CONTROL MODULE 2
LOGIC
LOGIC HYBRID/EV ELECTRONICS COOLANT PUMP (LEFT FRONT OF ENGINE COMPT)
RED/BRN WIRE
RED/WHT WIRE
SEAT/BSMESS FAN FUSE
SENS LOW REF
SENS SIG
SERIAL DATA (-) (1)
TEMP SENS SIG
TPIM MGU PMP FUSE
UNDERHOOD FUSE BLOCK
VIO/BLU WIRE
WHT WIRE
YEL/GRN WIRE
YEL/GRY WIRE
Go to component -> Automatic a/c circuit (6 of 6) -> COOL MTR CTRL
cool mtr ctrl wiring diagram (2 of 2)
BATT POS VOLT
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BRN/BLU WIRE
BRN/GRN WIRE
COMPUTER DATA LINES SYSTEM
COOL FAN CTRL
COOL MTR CTRL
FEEDBACK SIG
GRN/VIO WIRE
GROUND
HOT AT ALL TIMES
HYBRID/EV ELECTRONICS COOLANT TEMPERATURE SENSOR
HYBRID/EV POWERTRAIN CONTROL MODULE 2 HYBRID/EV BATTERY PACK
LOGIC
LOGIC HYBRID/EV ELECTRONICS COOLANT PUMP (LEFT FRONT OF ENGINE COMPT)
RED/BRN WIRE
RED/WHT WIRE
SEAT/BSMESS FAN FUSE
SENS LOW REF
SERIAL DATA (-) (1)
TEMP SENS SIG
TPIM MGU PMP FUSE
UNDERHOOD FUSE BLOCK
VIO/BLU WIRE
WHT WIRE
YEL/GRN WIRE
YEL/GRY WIRE
Go to component -> Hybrid cooling fan circuit -> COOL MTR CTRL
