Warning system circuits for Chevrolet Lumina I (1989-2001)

238 238 SUPPLEMENTAL RESTRAINTS SYSTEM BLK WIRE BLK/WHT WIRE DRIVER SEAT BELT SWITCH (IN DRIVER'S SEAT BELT ASSEMBLY) ENGINE WIRING HARNESS JUNCTION BLOCK 2 (FORWARD OF LEFT FRONT STRUT TOWER) FASTEN BELTS WARNING IND FUSE 10 FUSE 39 FUSE BLOCK GROUND FASTEN BELTS OUTPUT IGNITION INPUT GRY/BLK WIRE HEAD OFF PARK HEADLAMP SWITCH HOT AT ALL TIMES HOT IN RUN, BULB TEST OR START IGNITION KEY WARNING SWITCH (INSIDE STEERING COLUMN ASSY) INSTRUMENT CLUSTER INTERIOR LIGHTS SYSTEM (HEADLIGHT SWITCH) LEFT FRONT DOOR LOCK LIGHTS ON INPUT BATTERY (B+) KEY-IN-IGNITION INPUT LT GRN WIRE NCA WIRE ORG/ WIRE PARK LPS FUSE PNK WIRE PPL SEAT BELT SWITCH INPUT SEO ONLY (1999) SEO SWITCH PANEL DIODE (I/P HARNESS, BEHIND DASH) SPEEDO DIM SWITCH (SEO ACCESSORY SWITCH PANEL) TAN WIRE YEL WIRE
