Trunk, tailgate, fuel door circuits for Chevrolet Lumina I (1989-2001)
Trunk, tailgate, fuel door circuits
BLK WIRE
BLK/WHT WIRE
BREAKOUT TO 36 PIN CONN, BEHIND RIGHT SIDE OF DASH)
ENGINE WIRING HARNESS JUNCTION BLOCK 1 (FORWARD OF RIGHT FRONT STRUT TOWER)
GRY WIRE
HOT AT ALL TIMES
LT GRN WIRE
LT GRN/BLK WIRE
ORG/ WIRE
R/CMPT REL FUSE
REAR COMPART- MENT LID LOCK RELEASE SWITCH
REAR COMPARTMENT LID LOCK RELEASE SOLENOID (CENTER OF TRUNK LID)
SOLID STATE
TRANSAXLE RANGE SWITCH (TOP OF TRANSAXLE)
W/O RKE W/ RKE
