Chevrolet Lumina I (1989-2001) Charging circuit

BATTERY BLK WIRE BRN WIRE CHARGE WARNING INDICATOR FUSE 39 FUSE BLOCK (RIGHT SIDE OF DASH) FUSIBLE LINK (10 GA-RUST) GENERATOR GENERATOR CONTROL HOT IN RUN, BULB TEST OR START INDICATOR LAMP CONTROL INSTRUMENT CLUSTER PNK WIRE POWER DISTRIBUTION SYSTEM RED WIRE STARTER SOLENOID
