Manual a/c circuit, standard for Chevrolet Lumina I (1989-2001)

Manual a/c circuit, standard (1 of 2)

Lumina Chevrolet I (1989-2001): Manual a/c circuit, standard (1 of 2)

Get access

1995 VFTC A/C SOLENOID B-LV B-LV NORM MAX BI-LEVEL SOLENOID RECIRC SOLENOID BLK WIRE BLOWER MOTOR BLOWER MOTOR RELAY (BEHIND RIGHT SIDE OF DASH) BLOWER MOTOR RESISTORS (BEHIND RIGHT SIDE OF DASH, IN PLENUM) BLOWER SWITCH BRN WIRE DEF BLEND HTR DEF BLEND HTR VNT DEF BLEND HTR VNT B-LV NORM MAX DEFROST SOLENOID DK BLU WIRE FUSE 14 FUSE 4 FUSE BLOCK HEATER SOLENOID HEATER-A/C CONTROL HOT AT AL TIMES HOT IN RUN LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE NORM MAX OFF ORG/ WIRE PPL RED WIRE SOLID STATE TAN WIRE TEMPERATURE CONTROL VACUUM/ELECTRIC SOLENOID (BEHIND DASH, RIGHT SIDE OF PLENUM) VNT B-LV NORM MAX WHT/BLK WIRE YEL WIRE

Manual a/c circuit, standard (2 of 2)

Lumina Chevrolet I (1989-2001): Manual a/c circuit, standard (2 of 2)

Get access

1995 VFTC 22 26 A/C REQUEST SENSOR INPUT A/C COMPRESSOR CLUTCH A/C COMPRESSOR CLUTCH DIODE A/C COMPRESSOR CLUTCH RELAY A/C CONT FUSE BLK WIRE BRN WIRE COOLING FAN CONTROL RELAY 2 COOLING FAN CONTROL RELAY 3 COOLONG FAN CONTROL RELAY 1 DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE ENGINE COOLANT FAN MOTOR 1 ENGINE COOLANT FAN MOTOR 2 ENGINE WIRING HARNESS JUNCTION BLOCK 1 ENGINE WIRING HARNESS JUNCTION BLOCK 1 (FORWARD OF RIGHT FRONT STRUT TOWER) FAN 3 FUSE HOT AT ALL TIMES HOT IN RUN, BULB TEST OR START LT BLU WIRE LT GRN WIRE MAXI FUSE 1 NCA WIRE ORG/ WIRE PCM BAT FUSE PNK WIRE RED WIRE RELAY CONTROL RELAY CONTROL RELAY CONTROL SENSOR GROUND RIGHT ELECTRIC ACTUATOR (BEHIND DASH, RIGHT END OF HEATER-A/C MODULE) SOLID STATE WHT WIRE WHT/BLK WIRE YEL WIRE
