Chevrolet Lumina I (1989-2001) wires cut and taped in right kick panel Wiring diagram
This page shows the only wiring diagram for the component.wires cut and taped in right kick panel, which is found in the car Chevrolet Lumina I (1989-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram wires cut and taped in right kick panel (1 of 1)
24 INCH WIRES CUT AND TAPED ABOVE ROOF EXTERIOR
90 INCHES FROM EDGE OF CARPET, COILED UNDER INSTRUMENT PANEL, IN RIGHT FOOTWELL
ALTERNATING FLASHER
BLK WIRE
BRN WIRE
CUSTOMER INSTALLED ACCESSORIES JUNCTION BLOCK
DK BLU WIRE
DK GRN WIRE
FUSE 15
FUSE 19
FUSE 6
FUSE BLOCK (ON RIGHT SIDE OF DASH)
GRY WIRE
HOT AT ALL TIMES
LAMP ASSEMBLY
LEFT FRONT SPOT- LAMP
LEFT REAR EMERGENCY VEHICLE REAR COMPARTMENT LID LAMP
LEFT REAR EMERGENCY VEHICLE REAR WINDOW PANEL LAMP
LT BLU WIRE
LT GRN/BLK WIRE
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
PPL
REAR COMPARTMENT COURTESY
RED WIRE
RED/BLK WIRE
RELAY PANEL
RIGHT FRONT SPOT- LAMP
RIGHT REAR EMERGENCY VEHICLE REAR COMPARTMENT LID LAMP
RIGHT REAR EMERGENCY VEHICLE REAR WINDOW PANEL LAMP
TAN WIRE
TO GRILLE LAMPS (CUSTOMER INSTALLED)
TURN SIGNAL SWITCH
W/ REAR WINDOW MOUNTED FLASHING WARNING LAMPS
W/O REAR WINDOW MOUNTED FLASHING WARNING LAMPS
WIRES CUT AND TAPED IN RIGHT KICK PANEL
YEL WIRE
Go to component -> Exterior lamps circuit, with police or emergency vehicle option -> WIRES CUT AND TAPED IN RIGHT KICK PANEL
