Chevrolet Lumina I (1989-2001) pwr window pwr sunroof circuit breaker Wiring diagram
This page shows the only wiring diagram for the component.pwr window pwr sunroof circuit breaker, which is found in the car Chevrolet Lumina I (1989-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pwr window pwr sunroof circuit breaker (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
BUICK OLDSMOBILE
BUICK, OLDS CHEVROLET PONTIAC
CHEVROLET
DK BLU WIRE
DK DK PPL
DK LT
DK LT PPL
DOWN
ECB
EXPRESS DOWN
EXPRESS DOWN MODULE
FUSE BLOCK (BEHIND RIGHT SIDE OF DASH, IN GLOVE BOX OPENING)
FUSE BLOCK (BEHIND RIGHT SIDE OF DASH, IN RIGHT DOOR OPENING)
FUSE BLOCK (ON RIGHT SIDE OF DASH)
GRN WIRE
GRY WIRE
HOT IN ACC, RUN OR DURING RAP
HOT IN RUN
ILLUMINATION LAMP
LEFT FRONT
LEFT FRONT WINDOW MOTOR
LEFT FRONT WINDOW SWITCH
LEFT REAR
LEFT REAR WINDOW MOTOR
LEFT REAR WINDOW SWITCH
LOCK OUT SWITCH
PONTIAC
POWER WINDOW CIRCUIT BREAKER
PPL
PPL DK
PWR WDO CIRCUIT BREAKER
PWR WINDOW PWR SUNROOF CIRCUIT BREAKER
RIGHT FRONT
RIGHT FRONT WINDOW MOTOR
RIGHT FRONT WINDOW SWITCH
RIGHT REAR
RIGHT REAR WINDOW MOTOR
RIGHT REAR WINDOW SWITCH
TAN WIRE
UP DOWN
YEL WIRE
Go to component -> Power window circuit -> PWR WINDOW PWR SUNROOF CIRCUIT BREAKER
