Chevrolet Lumina I (1989-2001) passenger temperature control Wiring diagram
This page shows the only wiring diagram for the component.passenger temperature control, which is found in the car Chevrolet Lumina I (1989-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger temperature control (1 of 1)
1995 VFTC
A/C SOLENOID
B-LV
B-LV NORM MAX
BI-LEVEL SOLENOID
BLK WIRE
BLOWER MOTOR
BLOWER MOTOR RELAY (BEHIND LEFT SIDE OF DASH)
BLOWER MOTOR RESISTORS (BEHIND RIGHT SIDE OF DASH, IN PLENUM)
BLOWER SWITCH
BRN WIRE
DEF BLEND HTR
DEF BLEND HTR VNT
DEF BLEND HTR VNT B-LV NORM MAX
DEFROST SOLENOID
DK BLU WIRE
DRIVER TEMPERATURE CONTROL
FUSE 14
FUSE 4
FUSE BLOCK
HEATER SOLENOID
HEATER-A/C CONTROL
HOT AT AL TIMES
HOT IN RUN
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
NORM MAX
OFF
ORG/ WIRE
PASSENGER TEMPERATURE CONTROL
PPL
RECIRC SOLENOID
RED WIRE
SOLID STATE
TAN WIRE
VACUUM/ELECTRIC SOLENOID (BEHIND DASH, RIGHT SIDE OF PLENUM)
VNT B-LV NORM MAX
WHT/BLK WIRE
YEL WIRE
Go to component -> Manual a/c circuit, dual zone a/c (1 of 2) -> PASSENGER TEMPERATURE CONTROL
