Chevrolet Lumina I (1989-2001) mirror motor pack left outside rearview mirror Wiring diagram
This page shows the only wiring diagram for the component.mirror motor pack left outside rearview mirror, which is found in the car Chevrolet Lumina I (1989-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mirror motor pack left outside rearview mirror (1 of 1)
BLK WIRE
BRN WIRE
ECB
ECB ECB
HOT AT ALL TIMES FUSE BLOCK FUSE 19 (ON RIGHT SIDE OF DASH)
LEFT MIRROR RIGHT MIRROR
LT BLU WIRE
LT GRN WIRE
MIRROR MOTOR PACK LEFT OUTSIDE REARVIEW MIRROR
MIRROR MOTOR PACK RIGHT OUTSIDE REARVIEW MIRROR
NCA WIRE
ORG/ WIRE
OUTSIDE REMOTE CONTROL REARVIEW MIRROR SWITCH
RED WIRE
RIGHT/ LEFT MOTOR
RIGHT/ LEFT MOTOR UP/ DOWN MOTOR
UP DN
UP DN UP
UP/ DOWN MOTOR
WHT WIRE
YEL WIRE
Go to component -> Power mirror circuit -> MIRROR MOTOR PACK LEFT OUTSIDE REARVIEW MIRROR
