Chevrolet Lumina I (1989-2001) low traction indicator Wiring diagram
This page shows the only wiring diagram for the component.low traction indicator, which is found in the car Chevrolet Lumina I (1989-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram low traction indicator (1 of 1)
1280 1281 PNK WIRE
17 640 BRAKE IN BATT
ABS FUSE
ABS MAXI- FUSE
ABS MOTOR PACK (ABS HYDRAULIC MODULATOR ASSEMBLY)
ABS WARNING INDICATOR
BLK WIRE
BRAKE WARNING INDICATOR
BRN WIRE
DATA LINK CONNECTOR (BELOW DASH, RIGHT OF STEERING COLUMN)
DK GRN WIRE
ELECTRONIC BRAKE CONTROL MODULE (EBCM) (LEFT SIDE OF BRAKE PEDAL BRACKET)
ELECTRONIC BRAKE CONTROL RELAY
ENGINE WIRING HARNESS JUNCTION BLOCK 2
EXC 2000
FUSE 10
FUSE 13
FUSE 39
FUSE BLOCK (RIGHT SIDE OF DASH) FUSE 23
HOT AT ALL TIMES
HOT IN RUN
HOT IN RUN, BULB TEST OR START
IGN LEFT SOLENOID RLY COIL CTRL
INDICATOR CONTROL
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER SYSTEM
LEFT FRONT ABS SOLENOID (ABS HYDRAULIC MODULATOR ASSEMBLY)
LEFT FRONT MOTOR
LEFT FRONT WHEEL SPEED SENSOR
LEFT REAR WHEEL SPEED SENSOR
LOW TRACTION INDICATOR
LT BLU WIRE
LT GRN WIRE
NCA WIRE
ORG/ WIRE
PNK WIRE
PPL
REAR MOTOR
RED WIRE
RIGHT FRONT ABS SOLENOID (ABS HYDRAULIC MODULATOR ASSEMBLY)
RIGHT FRONT MOTOR
RIGHT FRONT WHEEL SPEED SENSOR
RIGHT REAR WHEEL SPEED SENSOR
STOPLAMP BRAKE SWITCH (ON BRAKE PEDAL SUPPORT)
TAN WIRE
TAN/WHT WIRE
WHT WIRE
YEL WIRE
Go to component -> Anti-lock brake circuits -> LOW TRACTION INDICATOR
