Chevrolet Lumina I (1989-2001) inside rear view mirror breakout) wiring diagram
This page shows the only wiring diagram for the component.inside rear view mirror breakout), which is found in the car Chevrolet Lumina I (1989-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
inside rear view mirror breakout) wiring diagram (1 of 1)
A/C CMPR RELAY
A/C CONT FUSE
AUTOMATIC TRANSAXLE
AUXILIARY DOME LAMP
AUXILIARY POWER DROP CONNECTOR
BLK WIRE
BLOWER MOTOR RELAY
CIGAR LIGHTER
DATA LINK CONNECTOR
DOOR LOCK RELAY REMOTE CONTROL DOOR LOCK RECEIVER (W/ KEYLESS ENTRY)
DRIVER'S SEAT ADJUSTER SWITCH
ELEC IGN FUSE
ENGINE WIRING HARNESS JUNCTION BLOCK 1 (RIGHT SIDE OF ENGINE COMPARTMENT)
F/INJN FUSE
FAN CONT 1 RELAY
FAN CONT 2 RELAY
FROM MAXI FUSE 2 (DIAGRAM 1 OF 4)
FROM MAXI FUSE 4 (DIAGRAM 1 OF 4)
FUEL INJECTOR 1
FUEL INJECTOR 2
FUEL INJECTOR 4 FUEL INJECTOR 3
FUEL INJECTOR 5
FUEL INJECTOR 6
FUEL PUMP RELAY
FUSE 10
FUSE 14
FUSE 28
FUSE 32
FUSE 37 FUSE 1
FUSE 41
FUSE 5 FUSE 23
FUSE BLOCK (RIGHT SIDE OF DASH) POWER SEATS CIRCUIT BREAKER D
FUSE BLOCK BREAKOUT)
HEATED OXYGEN SENSOR 1 HEATED OXYGEN SENSOR 2
I/P COMPARTMENT LAMP
IGN SYST RELAY
IGNITION CONTROL MODULE
INSIDE REAR VIEW MIRROR BREAKOUT)
INSIDE REARVIEW MIRROR
MASS AIR FLOW SENSOR EVAPORATIVE EMISSION CANISTER PURGE SOLENOID VALVE
NCA WIRE
OPTIONAL NON SEO
ORG/ WIRE
PCM BATT FUSE
PCM IGN FUSE
PNK (VIN K) (VIN M) WIRE
PNK PNK WIRE
PNK WIRE
POWERTRAIN CONTROL MODULE
PPL
R/CMPT REL FUSE
RADIO
RED WIRE
RIGHT SUNSHADE ILLUMINATED MIRROR DOME LAMP
SEATBELT/ IGNITION KEY/ LAMPS MODULE ELECTRONIC BRAKE CONTROL MODULE
SEO
THEFT DETERRENT MODULE
TO FUSE 15 (DIAGRAM 3 OF 4)
TO FUSE 19 (DIAGRAM 3 OF 4)
TRANS FUSE
TRANSAXLE RANGE SWITCH
TURN SIGNAL SWITCH STOP LAMP SWITCH
Go to component -> Power distribution circuit (2 of 4) -> INSIDE REAR VIEW MIRROR BREAKOUT)
